Magnesiumanode TYP 60 - 23.62*7.67*1.96, (29.92inch in total), appr. 13.2Lb. AZ63-1,5VDc
Article: B310600
- Total length: 600mm/23.62in
- Width: 165mm/6.50in
- Height: 50mm/1.97in
- Hole distance:
- Net weight: 5,11kg/11,27lb
- Gross weight: 6kg/13.23lb
- Reinforcement: FE
| PCS | Discount | Price |
|---|---|---|
| 5 | 5 % | €206,11 /st |
| 10 | 10 % | €195,26 /st |
| 20 | 15 % | €184,41 /st |
| 50 | 20 % | €173,56 /st |
Product description
Product specification
Type 60 magnesium
Material:Magnesium
Alloy: AZ 63B
Article: B310300
- Product drawing
- Net weight: 5.11kg
- Gross weight: 6kg
- Reinforcement: Steel
- Total length: 600mm
- Length: 460mm
- Width: 165mm
- Height: 50mm
Mounted with bolt or welded to object. (no pre-drilled holes in product)
Application areas:
- Ship hull
- Port infrastructure
- Buoys
- Cable
- Pipeline
- Pumps
- Pontoons
- Bridges
- Jetties
Magnesium anodes are mainly used in brackish water and fresh water. Magnesium anodes can be used in brackish water if resistivity exceeds about 1.0 Ωm.
With over 30 years of experience, you as a customer can always feel safe with our products. We manufacture everything according to international standards and industry guidelines. Each batch with anodes undergoes careful testing and quality assurance, so it has been for over 30 years ...
Not sure what type of material to use?Ask us, we can!
Technical data
- Capacity: 1230 AH/kg
- Consumption: 13.3 kg/A year
- Efficiency: appr 55%
- Potential: -1,500 mv Rel AG/AGCL in seawater
Typical chemical composition, AZ 63B (most common alloy in freshwater), magnesium.
|
Material |
% of weight |
|
Aluminum (al) |
min 5.3 max 6.7 |
|
Zinc (zn) |
min 2.5 max 3.5 |
|
Manganese (mn) |
>0,3 |
|
Silicon (si) |
~0,1 |
|
Copper (CU) |
<0,05 |
|
Iron (FE) |
<0,01 |
|
Magnesium |
Remaining |
Information
Extend the lifespan of your marine investments, check the product description for more information.
